Xerox DocuMate XDM6440-U Document Scanner
secure transaction
- Scan speeds up to 40 ppm / 80 ipm at 300 dpi, 60 ppm / 120 ipm at 200 dpi
- 6,000 page daily duty cycle
- Ultrasonic Double Feed Detection
- ADF Capacity: 80 sheets (20 lb. paper)
- Interface: Hi-speed USB 2.0 (3.0 compatible)
- Simplex or Duplex: Duplex (two side scanning)
- Speed @ 300 dpi, b&w, grayscale, or color: 40 ppm / 80 ipm
- Speed @ 200 dpi, b&w, grayscale, or color: 60 ppm / 120 ipm
- Visioneer OneTouch scanning to multiple applications
- Optional integrated Passport Scanner Accessory for identity capture
- Dimensions (W×D×H): 12.5 x 26.8 x 9.4 in
- Weight 9.2 lbs
Xerox DocuMate XDM6440-U Document Scanner
Scan Method Duplex Automatic Document Feeder Optical Resolution 600 dpi Interpolated Resolution with Visioneer Acuity 50, 75, 100, 150, 400, 500, 1200 dpi Image Sensor CCD (Charge Coupled Device) Light Source LED (light emitting diode) instant on Background Black Output Bit Depth 24-bit color, 8-bit grayscale, 1-bit black & white Scanning Media Supported Paper, plastic ID cards, photos Interface Hi-speed USB 2.0 (3.0 compatible) Maximum Card Thickness 0.051" (1.25 mm) Scanner Dimensions (paper trays extended) 12.5" x 26.8" x 9.4" (316 x 680 x 239 mm) Scanner Dimensions (paper trays collapsed) 12.5" x 7.5" x 6.6" (316 x 191 x 168 mm) ADF Minimum Document Size 2" x 2" (51 x 51 mm) ADF Maximum Document Size 9.5" x 118" (241 x 2997 mm) @ 200 dpi Maximum Scan Area 8.5" x 118" (216 x 2997 mm) @ 200 dpi ADF Paper Thickness Range 7 – 110 lbs. (27 ~ 413 g/m2) ADF Capacity 80 pages (20 lb., 75~80 g/m2 paper) Weight 9.2 lbs Duty Cycle 6,000 pages
Onsite Service
Following your purchase, JTF will assign an authorized service partner in your area to your account. Your service calls are processed and dispatched in just minutes after they are received, thus minimizing your downtimes. All service partners are authorized, factory trained and 100% endorsed by JTF Network Partners, with over 600 service dealers nationwide*
Same Day Onsite Service:
Same Day Service is provided at your business or home during the contracted Maintenance period.
Exceptions:
1) Your offices are 40 miles away from the closest service providers.
2) Service in HI, AK & PR.
Convenient Assistance:
Having device issues?
Experts are here 8am -6pm weekly to help solve your technical problems.
Fast, free replacements:
If we can’t fix your printer, we’ll try to replace it by the next business day.
No hidden fees:
Parts and labor, replacements, even return shipping — it’s all covered by your JTF Warranty.
Optional extra coverage:
Additional coverage to include supplies are available for purchase.
No Expert Install
$149.00 Expert Install
Installation Service for equipment includes the following:
JTF will schedule an appointment with one person per site. Unless otherwise requested and/or scheduled, the standard practice is to start all installation services within one week the delivery of the hardware to the customer’s location.
Unpacking: JTF will inventory the shipment against the packing list, unpack and install all delivered products.
Setup/Installation: JTF will physically assemble, connect peripherals, network cables, and power cords that were purchased from JTF.
a. This service provides installation of drivers on a single PC workstation (not server), network setup, including the programming of the IP address and network settings and verification of the network functionality, wireless connection setup and verification of the functionality over the Internet.
b. For configuration networking, the Customer can choose between automatic configuration using BOOTCP or Dynamic Host Configuration Protocol (DHCP), or manual configuration with IP address, default gateway, and subnet mask.
c. For multifunction products, the service provides setup of the ‘send to email configuration’ and configuration of the SMTP or LDAP.
d. This service provides the Customer-identified key operator with a basic overview on how to install consumables, plus explanations of basic features and functionality such as drivers, control panel features, embedded Web server, and alerts.
